Box with twelve drawing templates Box with Drawing Molds, Box with twelve drawing templates for trusses and curves of different ships. The truss jigs give half the large truss for a 74-piece ship of the line (fifteen-piece truss, seven-piece mold), for a 44-piece frigate (eleven-piece truss, five-piece mold) and for a corvette (truss of eleven parts, mold without belly piece five parts). Of the molds for the curves, there are three for heavy wood of the largest dimensions, three for that of average dimensions and three for that of the smallest dimensions, each indicating the largest, average and smallest bend., anonymous, Netherlands, 1827, wood (plant material), paper, h 6.3 cm × w 53 cm × d 18.5 cm
Keywords:
Box, twelve drawing templates Box, Drawing Molds, twelve drawing templates, trusses, curves, different ships, truss jigs give half, large truss, 74-piece ship, line, fifteen-piece truss, seven-piece mold, 44-piece frigate, eleven-piece truss, five-piece mold, corvette, truss, eleven parts, mold, belly piece five parts, molds, three, heavy wood, largest dimensions, average dimensions, smallest dimensions, indicating, largest, average, smallest bend, Netherlands, 1827, wood, plant material, paper
