Ceiling constructions, floor plans and cross-sections, Carl von Hasenauer (Vienna 1833 - 1894 Vienna), November 12, 1850, architectural drawing, pen and ink in black, pencil, watercoloured, sheet: 53.4 cm x 36.4 cm, 'Tramboden./ Sturzboden', 'The distance of the individual, / individual strands from each other is/ usually 3' from bundle to bundle side.', 'The use of tram floors, / the strength of the strands is approximately/ with ordinary loads:/ up to 9' long 5/6', From 9 - 12'' 5/7'/ '' 12 - 15'' 6/8'/ '' 15 - 18' 2 2 7/9'/ '' 18 - 21'' 8/10 '/ ' ' 21 - 24' ' ' 9/12'/ With a heavy load in/ magazines (sic):/ Up to 12' long 6/8'/ From 12' 15' ' ' 7/9'/ ' 15 ' 18' ' ' 8/10'/ ' 18 ' 21' ' ' 9/12' ', 'part bottoms', 'profile of/ changeover and finisher', 'profile of/ changeover (sic) and finisher', 'substitutions '
