Dippel floors, constructions, ground plans and sections, Carl von Hasenauer (Vienna 1833 - 1894 Vienna), 1851, Architectural drawing, black pen, watercolour, pencil; verso: pencil, 558 x 383 mm, recto: 'Dippelboden/ Geschnitten', 'Das gewerkliches Verstand, / niß (sic) the thickness to the length is/ with cut (sic) trees approx. following:/ Up to 10' in length 5/6' thick/ '15'' ''6/7''/ '18'' ''6/8' (inserted in pencil: 7/8)''/ ' 20' ' ' ' 7/8' ' ' [without particular L...]', 'Hauled', 'The applicable ratio (sic) is/ with hawt (sic) trees approximately:/ In length from 18 to 21', 8/9' strong/'' '' 21'' 24', 9/10''''/'' '' 24'' 30', 10/11' (inserted in pencil: 10/12)''/ the latter samples ... subdued./ Over 30' tram, / floors are used or ...', 'maximum change length without support: 4' ', 'substitution with cut. Trees (sic)', 'Exchange with hewn trees' verso: '23') On the attic 8/9'/ 9/10' dreams (crossed out) hewn dippel floor/ 10/11' dreams 2' 6' far apart', ' Up to 3° 6/7' cut double trees/ ' 4° 8/9' hewn do/ over 4° 9/10' do do/ with 5° thrusts '
