Henry VII Chapel, Plan of the Western and the South aile with an indication of the groining of the Roof, Stalls, Floor plan of the west side of the Henry VII Chapel in Westminster Abbey, signed: Engrav'd by John Roffe, from a Drawing by F. Mackenzie, Fig. 10, Pl. II, to p. 10, Mackenzie, F. (drawing); Roffe, John (engr.), 1812, John Britton: The architectural antiquities of Great Britain: represented and illustrated in a series of views, elevations, plans, sections and details of various ancient English edifices: with historical and descriptive accounts of each. Bd. 2. London: J. Taylor, 1807-1826
