Perspective studies on a cube, Carl von Hasenauer (Vienna 1833 - 1894 Vienna), May 18, 1853, architectural drawing, pen and ink in black, red and blue, sheet: 41.9 cm x 60.1 cm, 'FRONTAL PERSPECTIV/ 1 case. If one surface is parallel to the image plane/ or the surface a b c d. lies in the image plane', '2 case. If the cube is over a corner and/ one edge is assumed in the image plane, / assumed. B. B, encounter points', 'If the encounter points cannot be plotted/ a height scale MN is arbitrarily assumed'
Keywords:
Perspective studies, cube, Carl von Hasenauer, Vienna 1833, 1894 Vienna, 18, 1853, architectural drawing, pen, ink, black, red, blue, sheet, 41.9 cm x 60.1 cm, FRONTAL PERSPECTIV/ 1 case, surface, parallel, image plane/, surface, b c d, lies, image plane, 2 case, cube, corner /, edge, assumed, image plane, / assumed, B, B, encounter points, encounter points cannot, plotted/, height scale MN, arbitrarily assumed
