RECENTLY PATENTED INVENTIONS. Engineering. Stromsburg Neb. Combined with a supporting frame in which a shaft is mounted are radially arranged cylinders within the frame the pistons being connected to a single crank arm of the shaft and the steam chests mounted on the frame outside the cylinders the engine being designed to utilize the steam to the greatest advantage and be run at a high rate of speed. ( Grabner and Henri Ruperti of Kupferhammer near Drackwede Germany. This invention relates to cylin der and piston motor engines and is designed to dis pense with the devices heretofore employed to distri bute the steam and to effect its distribution directly from the source of supply alternately to the ends of the cylinder and piston the device being applicable to single and double acting engines. Caricienne Bertie La. Combined with a boiler feed pipe arranged in a furnace chamber is an independ ent detachable core having radial arms serving as supports for holding the core centrally in the pipe the construction providing an unusually large area of heat ing surface relative to the quantity of water passing through the supply pipe. Engelbach Leadville Col. This invention consists of a slide valve and a semi-cylindrical valve seat on which the slide valve operates and which is mounted to be turned in the steam chest the valve being simple and durable in construction effective in operation and permitting of quickly reversing the engine at any time. Railway Appliances. Rahway N. J. This is a stall for use in railroad cars etc. for the transportation of horses and cattle and designed to be readily set up and knocked down con sisting of a series of posts each having a screw rod for fastening them in place partitions to be hooked on op posite posts to form the sides an auxiliary post to lock the animals in place and feed bags or troughs held on this post. Homer City ?a. Combined with the drawhead is a gate and a lever connected therewith through the medium of a link that wor
