Roof truss constructions, cross sections, Carl von Hasenauer (Vienna 1833 - 1894 Vienna), February 12, 1851, architectural drawing, pen in black and red, watercoloured, pencil, 581 x 360 mm, 'Neuer Constructionen/ nach Ranek von 7 bis 8 Klaft. span', 'Ranek on a span of 11° a central slope column', 'Fellner for apartment buildings using the dividing walls', 'Berlin purlin roof'
Keywords:
Roof truss constructions, cross sections, Carl von Hasenauer, Vienna 1833, 1894 Vienna, February 12, 1851, architectural drawing, pen, black, red, watercoloured, pencil, 581 x 360 mm, Neuer Constructionen/ nach Ranek von 7 bis 8 Klaft, span, Ranek, span, 11°, central slope column, Fellner, apartment buildings using, dividing walls, Berlin purlin roof
