Vienna-Döbling, house Diemgasse 1, residential building of the municipality of Vienna, apartment table, Alfred Castelliz (Celje 1870 - 1940 Vienna), 1928, architectural drawing, Aquafix; Pencil sketch and pen drawing, 37.5 x 44.8 cm, 'RESIDENTIAL BUILDING OF THE COMMUNITY VIENNA XIX. HEILIGENSTAEDTERSTR 146/ DIEMGASSE 1/ APARTMENT TABLE/ 1 APARTMENT À 20 m² with Vorz. Z. 3%/ 24 APARTMENTS À 40 m² PREV. CU. Z. KA 68.5%/ 6 ' 48m² PREV. CU. Z. 2 KA 17%/ 4 ' 55m² PREV. CU. 2Z. KA 11.5%/ TOTAL 35 APARTMENTS/ CONSTRUCTION AREA 726m² - 100%/ BUILT-UP AREA 456m² - 63%/ UNBUILT AREA 270m² - 37%/ PLAN AUTHOR: CIVILIAN. PROF. A. CASTELLIZ VIENNA, 13. HERMIT. 32'
Keywords:
Vienna-Döbling, house Diemgasse 1, residential building, municipality, Vienna, apartment table, Alfred Castelliz, Celje 1870, 1940 Vienna, 1928, architectural drawing, Aquafix, Pencil sketch, pen drawing, 37.5 x 44.8 cm, RESIDENTIAL BUILDING, COMMUNITY VIENNA XIX, HEILIGENSTAEDTERSTR 146/ DIEMGASSE 1/ APARTMENT TABLE/ 1 APARTME, Vorz, Z, 3%/ 24 APARTMENTS À 40 m² PREV, CU, Z, KA 68.5%/ 6, 48m² PREV, CU, Z, 2 KA 17%/ 4, 55m² PREV, CU, 2Z, KA 11.5%/ TOTAL 35 APARTMENTS/ CONSTRUCTION AREA 726m², 100%/ BUILT-UP AREA 456m², 63%/ UNBUILT AREA 270m², 37%/ PLAN AUTHOR, CIVILIAN, PROF, A, CASTELLIZ VIENNA, 13, HERMIT, 32
